Smart Building Cybersecurity - BMS Threats and Protection

In September 2023, the Dark Angels group hit Johnson Controls with ransomware - one of the world’s largest manufacturers of HVAC systems, access control, and fire protection. Net loss: 27 million dollars. In 2025, a Claroty study found that 75% of organizations have BMS devices with publicly known exploited vulnerabilities, and 51% have those devices connected to the internet in a way that enables ransomware attacks.

Smart buildings are not just concrete and glass. They are facilities packed with automation systems - from HVAC and lighting control to video surveillance, access control, and elevator management. Each of these systems is a potential attack surface. And unlike IT systems, the consequences of an attack on a Building Management System (BMS) are not data loss - they are building evacuation, server room cooling failure, access control bypass, or lighting shutdown.

What is a Smart Building and Why It Is Vulnerable

A smart building is a facility where building automation systems (BMS - Building Management System) integrate HVAC management, lighting, access control, surveillance, elevators, and fire systems. Typical facilities include office buildings, shopping malls, hospitals, airports, data centers, and hotels.

The security problem stems from history. Building automation protocols - BACnet, KNX, LONworks - were created in the 1980s and 1990s, when functionality mattered, not cybersecurity. Initially, they communicated over dedicated wiring (copper twisted pair, bus). Ethernet and wireless connectivity were added later - which opened previously isolated systems to the outside world.

BMS Protocols - Security Status

Protocol	Standard	Authentication	Encryption	Secure Version	Adoption Status
BACnet	ASHRAE 135	None (BACnet/IP)	None	BACnet/SC (2020) - TLS 1.3, X.509	Low - most installations are legacy BACnet/IP
KNX	EN 50090	None (KNX Classic)	None	KNX Secure (2021) - AES-128	Low - certification exists, adoption in installations minimal
LONworks	ANSI/CEA-709	None	None	None	None - protocol considered legacy
Modbus TCP	Modbus.org	None	None	Modbus/TCP Security (2018) - TLS	Very low

The pattern is the same across all protocols: standards have added security on paper, but the installed base of devices does not support it. Most buildings use devices installed 10-20 years ago, with no upgrade path.

How Attackers Exploit BMS

Internet Exposure

One of the main attack vectors is exposing BMS systems to the internet - often unintentionally. Tools such as Tenable Attack Surface Management can identify BACnet devices (UDP 47808), KNX (UDP 3671), and Modbus (TCP 502) accessible from the internet. Data from 2024 shows approximately 110,000 ICS/OT devices directly reachable from the internet, with BACnet accounting for approximately 8.9% (Forescout research).

Access to many of these systems is possible using default passwords or without any login. A 2019 incident (Safety Detective) revealed unsecured browser access to RDM BMS systems across 319 facilities globally, including ten hospitals in the United Kingdom.

BMS Integration with Corporate Networks - New Attack Vectors

Since 2019, a key shift has been the transition to cloud-managed BMS. Building operators want energy dashboards, remote diagnostics, and predictive maintenance - which requires internet connectivity. In practice, three dangerous topologies emerge:

1. BMS controller with direct internet access - flat network, no segmentation
2. BMS connected to the corporate network for energy reporting - risk of lateral movement to IT
3. Cloud-managed BMS (Siemens Desigo CC, Honeywell Forge, Johnson Controls OpenBlue) - vendor cloud as the attack surface

Building systems rarely have dedicated security teams. Unlike industrial process control systems, BMS is often managed by facility management companies, for whom cybersecurity is not a core competency. This gap is visible in incident data.

Attack Examples

Incident	Year	Target	Impact
Google Australia	2013	NiagaraAX BMS system - vulnerability allowing admin password readout	Compromise of Google’s Sydney headquarters
Target (USA)	2013	Entry vector through HVAC subcontractor system	Theft of 40 million payment card records
US Hospitals (WannaCry)	2017	Hospital systems including BMS	Ward closures, patient transfers
Johnson Controls	2023	Dark Angels ransomware on BMS manufacturer’s IT infrastructure	$27M in losses, data breach
Omni Hotels	2024	Room key systems, check-in, payments	Multi-day disruption to guest services

Who Is Responsible for Smart Building Security

Responsibility for BMS security is blurred by the building lifecycle structure. Multiple stakeholders are involved in a project: the investor, general contractor, subcontractors (BMS installers, security systems integrator), and then building management, service companies, tenant IT departments, and external entities.

Key questions that should be asked at every stage:

• Was cybersecurity considered during the BMS design phase?
• Were security aspects taken into account when selecting devices and manufacturers?
• Were security tests of the entire system performed during building commissioning?
• Who verifies the security posture during the operational phase?

Protecting Smart Building Systems

Segmentation - The First Line of Defense

The IEC 62443 zones and conduits model applies to buildings just as it does to industrial plants. The BMS should reside in its own OT zone, separated from the corporate network by firewalls. Remote access to BMS - only through a jump server in the DMZ, never directly from the internet.

Protocol Hardening

For new installations, require BACnet/SC (TLS 1.3) and KNX Secure (AES-128). For existing installations - compensating controls: segmentation, monitoring, access control to configuration panels.

Asset Inventory

Most BMS operators cannot list all connected devices. Asset inventory is the starting point - passive tools (Nozomi, Claroty) now support the BACnet protocol and can discover building devices without impacting their operation.

Regulatory Requirements

NIS2 / KSC

The NIS2 directive covers essential entities in the energy, health, water, and digital infrastructure sectors - sectors that operate large building facilities. BMS systems in hospitals, data centers, and critical infrastructure buildings fall within scope as part of the OT attack surface. A BMS incident in a hospital (e.g. HVAC failure in an operating room) is subject to reporting within 24 hours. KSC is the Polish national transposition of the NIS2 directive.

EU Cyber Resilience Act

The CRA (adopted 2024, technical requirements effective December 2027) covers products with digital elements sold in the EU - including BMS components. Manufacturers will need to build in security by design and provide an SBOM (Software Bill of Materials).

IEC 62443

The standard is increasingly applied in the building context. Manufacturers such as SAUTER and Siemens Building Technologies publish BMS security assessments based on IEC 62443. The most relevant parts for buildings: 62443-2-1 (security program) and 62443-3-3 (system requirements, zones and conduits). An IEC 62443 audit allows you to assess BMS compliance with the standard’s requirements.

Smart Building Security Checklist

Area	Element	Description
Inventory	BMS device register	List of all controllers, sensors, actuators with firmware and addresses
	BMS network map	Network topology identifying connections to IT and the internet
Segmentation	Separate BMS network	VLAN + firewall separating BMS from IT
	Safety system isolation	Fire, emergency voice, ESD systems in a separate segment
	No internet access	No BMS device directly reachable from the internet
Access	Change default passwords	Admin passwords changed on every device
	MFA for remote access	Multi-factor authentication on VPN/management portal
	Individual service accounts	No shared accounts for service companies
Monitoring	IDS on BMS network	BACnet/KNX/Modbus protocol monitoring (e.g. Nozomi, Claroty)
	Access logs	Logging of all remote sessions and configuration changes
Updates	Controller firmware	Regular verification of update availability
	SBOM	Knowledge of software components in BMS devices
Procedures	Incident response plan	Procedure for responding to attacks on BMS systems
	Change management	MOC procedure for BMS configuration changes

Smart building security starts with asset inventory and network segmentation - and does not require replacing the entire installation. If you want to assess the security posture of BMS systems in your facility, we can conduct an IEC 62443 compliance audit or penetration testing of the building OT network.

Sources

• Claroty - Widespread cyber risks in BMS including ransomware-linked KEVs (2025)
• ASHRAE 135 - BACnet/SC (Secure Connect)
• IEC 62443 - BMS Compliance and NIS-2
• NIST SP 800-82 Rev. 3
• EU Cyber Resilience Act (2024)
• Forescout - Global threat evolution of internet-exposed OT/ICS (2024)
